Wire rod

Wire rod is a hot rolled alloy or non-alloy steel product, produced from billets. Particularly fine cross-sections may be achieved by subsequent cold forming.
it wounded into coils and transported in this form.

Unlike rebar, it is used in many applications rather than reinforced concrete structures, It Also provides huge diameters ranging from 5.5mm to 15mm strength and in standard lengths of 100-130 CM with exceptional mechanical properties that can be controlled by the addition of different elements during alloying and controlling its process parameters as well as thermo-mechanical rolling to meet the end-user.

Wire Rod Uses:

Reinforcing concrete structures.
Aluminum and Copper rod.
Welding electrodes.
Drawn and galvanized wire.
Nails, bolts, and tacks.
Sling wire rope.
Electrical components and household goods.
Electric cable armoring.
Furniture springs.
Automotive components.
Fasteners and fixings.
Wire mesh.
Aviation.

Wire Rod

Wire rod Specifications


Size Coil weight Inner coil Diameter Outer coil Diameter Length
5.5 to 14 mm Around 1.5 Ton 85 to 100 cm 100 to 130 cm 100 to 130 cm


Wire rod Grades


Steel Grade                                                     Chemical Composition (w.t%)
C Si Mn P S
AISI 1006  Min. 0.00 0.00 0.25 0.000 0.000
Max. 0.08 0.10 0.40 0.040 0.050
AISI 1008 Min. 0.00 0.00 0.30 0.000 0.000
Max. 0.10 0.20 0.50 0.040 0.050
AISI 1010 Min. 0.08 0.00 0.30 0.000 0.000
Max. 0.13 0.30 0.60 0.040 0.050
AISI 1012 Min. 0.10 0.00 0.30 0.000 0.000
Max. 0.15 0.30 0.60 0.040 0.050
AISI 1013 Min. 0.11 0.00 0.50 0.000 0.000
Max. 0.16 0.30 0.80 0.040 0.050
AISI 1015 Min. 0.13 0.00 0.30 0.000 0.000
Max. 0.18 0.30 0.60 0.040 0.050
AISI 1017 Min. 0.15 0.00 0.30 0.000 0.000
Max. 0.20 0.30 0.60 0.040 0.050
AISI 1018 Min. 0.15 0.00 0.60 0.000 0.000
Max. 0.20 0.30 0.90 0.040 0.050
AISI 1020 Min. 0.18 0.00 0.30 0.000 0.000
Max. 0.23 0.30 0.60 0.040 0.050
AISI 1022 Min. 0.18 0.00 0.70 0.000 0.000
Max. 0.23 0.30 1.00 0.040 0.050



For more information about the technical specifications, please visit the Certifications page.
